Precise - versatile - robust
For the STAGO - Stapling machines functionality, precision and a high ease of use are always in the foreground. Robust mechanics, durability of materials and modern urges are the warranties for a perfectly long-running function.
STAGO- Stapling machines are equipped with electrically secured protection with a visual display (only automatic machines) and a depot display. Contact us!
| The USM series models are clearly the flagships of staplers. They feature the highest variability and an enormous stapling capacity of up to 250 sheets (80g plain paper). Depending on the model, stapling with up to 6 stapling heads is possible. The spacing can be freely selected within the range of 40-360 mm. STAGO-typical robust design for continuous daily use. An active clencher matrix and an infinitely variable stapling thickness adjustment guarantee a perfect stapling result. Due to very short conversion times between different usage scenarios (flat-, saddle stapler, flat-, loop staple, different dimensions, etc.), the USM series is economical on short runs. For larger brochure editions we recommend the optional automation unit BMK1800. |
| Features and technical equipment | |||
|---|---|---|---|
| USM 140 | USM 240 | USM 360 | |
| Stapling heads | 1-2 | 1-4 | 1-6 |
| Distance between heads | 40-140 mm | 40-240 mm | 40-360 mm |
| Flat stapling | 2-250 sheets (25mm, 80g paper) | 2-250 sheets (25mm, 80g paper) | 2-250 sheets (25mm, 80g paper) |
| Saddle stapling | yes | yes | yes |
| Staples (sizes) | K24/6-22, K50/20-27, KRi24/6-8 | K24/6-22, K50/20-27, KRi24/6-8 | K24/6-22, K50/20-27, KRi24/6-8 |
| Automation | no | BMK 1800* | no |
| Working height | 880 mm | 880 mm | 880 mm |
| Machine dimensions | 1500 / 620 / 800 mm | 1500 / 620 / 800 mm | 1500 / 740 / 800 mm |
| Weight | 83 kg | 105 kg | 140 kg |
| Power supply | 230V / 50Hz | 230V / 50Hz | 230V / 50Hz |
| * optional Further models and special solutions are available, please send us your request. | |||
